Automatic Optical Inspection (AOI) system 2D Statistical Process Control (SPC) Board size inspection area: 21" x 21" Board inspection area: 1.96" x 1.96" Camera resolution: 2352 x 1728 Pixel size: 8 µm Operating system: Windows XP SMEMA2 Power supply: 115 V, 50 Hz, 10 A

Last check June 2023 here is what needs to be done: A damaged PCB clamping guide was noticed. The transport belts are in poor condition. The mirrors in the camera module must be cleaned before calibration

Konfiguracja standardowa: Integral Machine Mounted Monitor and PC Inerted Nitrogen System Auto Solder Top-up (Wire Feed) & Solder Level Detect Single Titanium Drop Jet Fluxer - 200 Micron Internal Fume Extraction Colour Programming Camera Universally Adjustable Tooling Carriers 508mm (X) x 457mm (Y) (20” x 18”) Maximum PCB Handling Size Manual Fiducial Correction System PillarPAD Offline Programming Package Thermal Nozzle Calibration System using Integrated Setting Camera (requires manual correction) PillarCOMMX Windows Software Solder Wave Height Measurement Process Viewing Camera Multilevel Password Security System Lead-Free Capability Set of AP Solder Tips (2.5mm, 3mm, 3.5mm, 4mm, 5mm, 6mm, 8mm, 10mm & 12mm) Standard Production Data Export (CSV File with Configurable Board Process Data) Accessory Kit Plus dodatkowe wyposażenie: Top Side IR Pre-Heat Closed Loop Thermocouple Top-Side Pre-Heat Control Initial Lead-Free Solder Fill – SAC305 Nitrogen Analyser - (Measures the oxygen content within the incoming nitrogen into machine). Real Time PCB Warp Correction System X, Y & Z Axis Encoders Vacuum Packaging (Jade MKII)

Here is a Versaflow. It is with dip and one selective solderpot. The solderpot is renewed a couple of years back. The machine is vwell maintained by us and is in full working condition Price 14500 euro

Szukasz rzetelnego partnera do montażu elektroniki? Oferujemy usługi Montażu Powierzchniowego SMT, idealne dla krótkich serii produkcyjnych i prototypów.
